| Series | LBC |
| Package | Tape & Reel (TR)Cut Tape (CT) |
| Part Status | Active |
| Type | Wirewound |
| Material - Core | Ferrite |
| Inductance | 100 mH |
| Tolerance | ±5% |
| Current Rating (Amps) | 20 mA |
| Current - Saturation (Isat) | - |
| Shielding | Unshielded |
| DC Resistance (DCR) | 420Ohm Max |
| Q @ Freq | 30 @ 79.6kHz |
| Frequency - Self Resonant | 120kHz |
| Ratings | - |
| Operating Temperature | -55°C ~ 125°C |
| Inductance Frequency - Test | 10 kHz |
| Features | - |
| Mounting Type | Through Hole |
| Package / Case | Axial |
| Supplier Device Package | - |
| Size / Dimension | 0.205" Dia x 0.472" L (5.20mm x 12.00mm) |
| Height - Seated (Max) | - |
